July 7, 2007

From LPOD
Jump to: navigation, search

Almost Mud

image by Bob Pilz

Past looks at the Delambre region revealed striations aligned in two directions - and this new view confirms them both. First is a general pervasive lination - little ridges and troughs - that trend from the upper left to the lower right. These lines radiate from the Imbrium impact basin and seem to be flow marks from when a mud (but not lubricated with water) of basin debris skidded over the surface. The second set of striations are much more delicate and only occur to the left (SW) of the bottom side of Delambre. The are shown more clearly on Carmelo’s earlier image, and are hinted at enough here to imply that they are real. The ejecta of Theon Junior (immediately left of Delambre) looks like it was pasty when deposited - it covers the terrain smoothly. And the poor crater Taylor (center left with peak) has had a veneer of ejecta splattered on its inner walls. Finally, notice the pleasing contrast between the highly textured highland surface and the very smooth lava of Mare Tranquillitatis.

Chuck Wood

Technical Details:
July 5, 2007, 08:55UT. 200mm f/6 Newtonian reflector, Televue 3x Barlow , DMK 21BF04 B/W camera, ‘Blue’ IR-block filter, .20 arcsec/pixel, 30 fps, 1/39 sec, 400/9000 frames stacked; processed in Registax V4, PS CS, Focus Magic. Taken from Lat: 35 degrees 36 minutes N, Long: 82 degrees 33 minutes W, Elev:~850m.

Related Links:
Rükl chart 46
Delambre at the-Moon Wiki

Yesterday's LPOD: Accidental Concentricity

Tomorrow's LPOD: Floating Lava
